Ultrasonic Flowmeter AUF761 Series

ALIA

Type

: AUF761 Series

Brand

: ALIA

Download PDF

SPESIFICATION
FEATURES

Measuring Principle : Transit time difference
Pipe Size : DN20-DN1000 mm
Flow Velocity : 0.3 ~ +/-12 m/s
Resolution : 0.001 m/s
Accuracy : +/-1% of reading
Repeatability : +/-0.2% of reading
Response Time : Less than 1 second
Process Temperatue : -40~70 °C
: -40~160 °C
Max. Pressure : 100 kgf/cm2
Process Connection : Thread (DN20-DN40)
: Flange (DN20-DN1000)
Flange Type : JIS 10K / JIS 20K / JIS 40K
ANSI 150# / ANSI 300# / ANSI 600#
DIN PN10 / PN16 / PN25 / PN40
Body Material : S.S. 304 / S.S. 316
Housing Material : Aluminum Alloy
Ambient Temperature : -20~50 °C
Protection Class : IP67
Explosion Proof : Ex d IIC T4
IR Remote Control : Intrinsically Safe, Ex ib IIC T6
Keypad : 4 Internal Keys / IR Remote Control
Display : 2 Lines LCD with illumination
Flowrate : 7 Digit with decimal point
Totalizer : 8 Digit, Forward, Reverse & Net values.
Engineering Unit : m3, L, USgal, USbbl, ft3
Time Unit : sec, min, hour, day
Other : Velocity, Date, Time, Signal condition
Installation : Compact or Remote
Max. Cable Length : 100 m
Power Consumption : Less than 2W
Power Supply : 90-260 VAC 50/60 Hz and 24 +/-10% VDC
Data Storage : Operation parameters and totalizer
figures are stored by EEPROM for more
than 10 years
Current Output : 4-20 mA
Load : Max. 800 Ω
Pulse Output : 1 unit / pulse (Passive)
Rating : 12-24 VDC, 100 mA Max.
Communication : RS485 (MODBUS)
Cable Entry : 1/2" NPT (Female) (Standrad)
: M20 * 1.5 (Option)

2 lines LCD display with flowrate, totalizer…
Stores up 720 Hours / 365 Days / 36 Months / 10 Years Totalizer value
Pipe size from DN20-DN1000 mm
High accuracy of +/-1% of reading
Bidirectional measurement
Various output types as 4-20 mA, pulse, RS485
With self-calibration function, real-time measurement calibration
Accurate and stable measurement
The sensor has anti-high temperature and long service life, It can reach to 200 °C in a short time
